Medical grade titanium alloy bars implanted titanium rod

$10 - 20 /piece

Payment Type:

L/C,Western Union,T/T,MoneyGram

Incoterm:

FOB,CFR,CIF,EXW

Min. Order:

1 piece

Transportation:

Ocean,Land,Air,Express

Port:

Shanghai,Tianjin,Shenzhen

Contact Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Place Of Origin: China

Brand Name: QYX, Qiyuexin

Application: Industrial

Shape: Round

Technique: Forged

Grade: Titanium

Processing Service: Bending

Warranty: 3 year

Product Name: Titanium Bar ASTM F136

Testing: Ultrasonic Testing

MOQ: 1 Piece

Customized Support: OEM

Supply Ability: 10000 Set/Sets per Month

Packaging Details: Export Standard Wooden case, or can be customized

Length: Customized

Weight: OEM

Material: Titanium

Supply Ability & Additional Information

Packaging: WOODEN CASE

Transportation: Ocean,Land,Air,Express

Supply Ability: 1000 Piece/Pieces per Month

Port: Shanghai,Tianjin,Shenzhen

Payment Type: L/C,Western Union,T/T,MoneyGram

Incoterm: FOB,CFR,CIF,EXW

Packaging & Delivery

Selling Units:: piece

Package Type:: WOODEN CASE

Medical grade titanium alloy bars Implanted Titanium rod

1. product Introduction
Titanium 6AL4V and 6AL4V ELI, alloys made of 6% Aluminum and 4% Vanadium, are the most common types of titanium used in medicine. Medical grade titanium alloy bars implanted titanium rod Because of its harmonizing factor with the human body, Medical Grade Titanium Bar these titanium alloys are popularly used in medical procedures, as well as in body piercings. Also known as Gr. 5 and Gr. 23, these are some of the most familiar and readily available types of titanium in the world. Surgical Use Titanium Material Medical Grade Titanium

Ti-6Al-4V and Ti-6Al-4V ELI offer greater fracture-resistance when used in dental implants. The implant procedure begins with the insertion of a titanium screw into the jaw. The screw resembles and acts like the root of the tooth. After an allotted amount of time has passed for the bone to have grown into the medical grade titanium screw, a fake tooth is connected to the implant.

2.product Parameter (specification)

Name	Medical Titanium bar/rod Medical grade titanium bar/rod Medical Titanium Alloy bar/rod Medical grade titanium alloy bar/rod
Standard	ASTM F136
Grade	Gr5Eli,Gr23
Diameter	Titanium bar for bone screw:6mm,8mm, 10mm,12mm Titanium bar for intramedullary13.5mm, 14.5mm, 16mm Titanium bar for dental:8mm, 20mm, 25mm,30mm Titanium bar for bone joint:30mm, 40mm, 65mm
Length	1000mm/3000mm/6000mm
Tolerance	h6,h7,h8,h9
Technique	Forging ,Machining
Surface	acid surface or polishing, sand blasted surface
Shape	Round, flat, square, hexagonal,hollow

3.Application:

1.Pins

2.Bone plates

3.Screws

4.Bars

5.Rods

6.Wires

7.Posts

8.Expandable rib cages

9.Spinal fusion cages

10.Finger and toe replacements

11.Maxio-facial prosthetics

Alloy	Specifications	UTS (psi)	YS (psi)	EI (%)	RA (%)
		ksi min.	ksi min.	% min.	% min.
CP-1	ASTM B265 / B348 Grade 1	35	20	24	30
CP-2	ASTM B265 / B348 Grade 2	50	40	20	30
CP-3	ASTM B265 / B348 Grade 3	65	55	18	30
CP-4	ASTM B265 / B348 Grade 4	80	70	15	25
Ti 6AI-4V	ASTM B265 / B348 Grade 5	130	120	10	25
Ti 6AI-4v ELI	ASTM B265 / B348 Grade 23	120	110	10	15
Ti-Pd	ASTM B265 / B348 Grade 7	50	40	20	30
TiCode 12	ASTM B265 / B348 Grade 12	70	50	18	25

item	titanium rod
Application	Industrial
Shape	Round
Length	Customized
Technique	Forged
Grade	titanium
weight	OEM
Processing Service	Bending, Welding, Cutting, Punching
Warranty	3 year
Product name	Titanium bar ASTM F136
Material	Titanium
Testing	Ultrasonic Testing
MOQ	1 Piece
Customized support	OEM
Supply Ability	10000 Set/Sets per Month
Packaging Details	Export Standard Wooden case, or can be customized

Baoji qiyuexin metal materials Co., Ltd. is located in the east zone of Shaanxi Baoji high tech Industrial Development Zone, which is known as "China Titanium Valley". It was established in 2018 with a registered capital of 3 million yuan. It is an enterprise long engaged in the processing and manufacturing of titanium and other rare metals. It has profound inside information and rich experience in the production of rare metals. The company has passed the ISO9001 quality management system certification. Over the years, with strong technical strength, high-quality and mature products and perfect quality management system, the company has achieved rapid development. So far, its products are exported to home and abroad. Baoji qiyuexin metal materials Co., Ltd. focuses on the production of Titanium Pipe Fittings, titanium, nickel, Zirconium, Molybdenum, flanges, pipe fittings and other non-standard products. Its products include bar, plate, pipe, wire, foil, special-shaped drawing processing parts of various metal materials, various metal composite diamond bits, and pipe targets, round targets and plate targets used in vacuum sputtering coating industry; And can provide customers with national standard (GB / T) and American Standard (ASTM) and other production technical standards of various metals and their alloy materials.
